OEM/ODM custom friction stir welding FSW aluminum alloy battery tray for electric vehicle

Aluminum alloy battery tray / lower box of battery pack is mainly made of steel and aluminum alloy. Aluminum alloy is favored by more and more automobile OEMs and manufacturers around the world because of its low density and various forming processes, which can meet the requirements of electric vehicle lightweight. At present, aluminum alloy battery tray has two process schemes: integral casting and aluminum profile welding. FSW has been widely used in the manufacture of battery tray because of its non melting, automation, intelligence, environment-friendly and integrated characteristics. As early as 2011, our team developed aluminum battery tray for German Renault automobile, which can realize the automatic welding production of aluminum battery tray. It is the first FSW aluminum alloy battery tray in the world. In recent years, our team has developed more than 30 kinds of aluminum battery trays for many domestic main engine manufacturers and their supporting enterprises, and invented equipment specially used for FSW welding of aluminum battery trays, which has increased the production efficiency by more than 100%.

With friction stir welding and die casting as the core technology, Cheeven produces many products such as friction stir welding water-cooled parts and die-casting products. The main production workshops include friction stir welding workshop, die-casting workshop, finishing workshop and post-treatment workshop. Qi Yun has the ability to inspect and detect products from raw material processing, die-casting, friction stir welding, precision machining and product surface treatment, Have a complete production line manufacturing capacity.

Equipment Capacity

With friction stir welding and die casting as the core technology, Cheeven produces many products such as friction stir welding water-cooled parts and die-casting products. The main production workshops include friction stir welding workshop, die-casting workshop, finishing workshop and post-treatment workshop. Qi Yun has the ability to inspect and detect products from raw material processing, die-casting, friction stir welding, precision machining and product surface treatment, Have a complete production line manufacturing capacity.



1,Friction stir welding

Cheeven is committed to the development, application and promotion of friction stir welding technology. He has rich experience in R & D and production of friction stir welding, especially in the design and manufacturing of battery tray, electric cabinet, motor products and aluminum alloy water cooling parts of new energy vehicles, It has independently developed friction stir welding technology with upper and lower double heads and intelligent visual friction stir welding technology, which is at the leading level in the same industry. After product welding, the company will conduct professional ultrasonic nondestructive testing and provide product testing report.

Equipment	Brand	Quantity
Table type Friction Stir Welding Equipment	Tanrand	3
Gantry type Friction Stir Welding Equipment	Tanrand	4
Upper and lower double head friction stir welding equipment	Tanrand	2
Refill Friction Stir Spot Welding Equipment	Tanrand	2

2,Die Casting Our die casting workshop is equipped with nine 200-280T , and one 1600T , 800T and 500T cold chamber die casting machines respectively , with complementary automatic soup feeding machines , sprayers , pick up machines , mold temperature machines and water /oil cooling systems to facilitate automatic die casting production . After the commissioning of the die , the material certificate , test report , drawings , spare parts , die use instructions qualified test template and model size report will be provided to the client

Equipment	Brand	Quantity
Die Casting Machine(280-1600T)	L.K.Group	12
Drilling Machine	Hangzhou west lake Drill Co.,Ltd	60
Semi Automatic Multi Axis Drilling	Customized	3
Press Machine	Customized	30
Hydraulic Press	Customized	3
Belt Mil	Customized	1
Rail Suspension Type Shot Blasting Machine	Li Kang Machinery	1
Crawler Type Rolling and Polishing Machine	Li Kang Machinery	1

3,CNC-Machining Cheeven has dozens of machining centers. With strict quality management, Qiyun can provide customers with various product machining services to meet customer needs.

Equipment	Brand	Quantity
Vertical CNC	Li Yang Machinery	9
High speed CNC	Taiwan Gentiger	15
CNC Lathe	Yuhuan Long Lathe Co.,Ltd	18
CNC Drilling and Milling machining Center	Haas Automation Asia Co.,Ltd	13
Gantry machining center	LWS	1

4,Post-Treatment According to client needs (drawings or samples ),Cheeven provides manufacturing , processing , sand blasting and shot blasting , baking finish , passivation , oxidation , powder spraying , electroplating and a series of back-end - services for zinc & aluminium die casting molds and products . Products include LED energy-saving lamp accessories , auto parts , communication parts , power tools accessories , medical devices , mechanical instrument accessories , etc .

Equipment	Quantity
Vibration Grinding	2
Shot Blasting Machine	2
Polishing Machine	12
Abrasive Belt Machine	2
Pretreatment Coating Line	1
Waste Gas Treatment Equipment	1
Waste Water Treatment Equipment	1

5,Quality Control We have the CMM measuring device,Ultrasonic testing equipment and conventional testing equipment to carry out Water cooling products, die casting products and full-scale inspection of key parts of die production to ensure quality stability . We have special mold testing workshop to detect problems and eliminate them through the process of small batch trial production . This effectively prevents early problems from passing on to clients , and ensures the timely mass production of the mold .

Equipment	Quantity
Ultrasonic nondestructive testing equipment	1
CMM	1
Projector	1
Vancometer	1
Thickness Meter	1
Salt-sparying Tester	1
Rockwell hardness tester	1
Metallurgical Microscope	1
